SS Centrifugal Pumps

Get a Price/Quote

SS Centrifugal Pumps Specification

Flow Rate
Up to 200 m/hr

Theory
Centrifugal Pump

Structure
Single Stage

Suction Type
Single Suction

Volute Type
Single Volute

Nozzle Location
End Suction, Top Discharge

Shaft Orientation
Horizontal

Power Source
Electric

Fuel System
Direct Drive

Pressure
Up to 10 bar

Temperature
Up to 120C

Inlet, Outlet Diameter
25 mm to 100 mm

Speed
1450/2900 rpm

Application
Water Transfer, Chemical Handling, Process Industries, Food Processing, Pharmaceuticals, Dairy, CIP

About SS Centrifugal Pumps

SS Centrifugal Pumps

Leveraging on our vast industry experience, we are offering our clients a finest quality range of SS Centrifugal Pumps. These pumps are manufactured by our professionals using excellent quality SS 316 and other material in compliance with international quality standards. The offered pumps are available in various technical specifications as per the need of our clients. These pumps are widely used for chemical transfer from underground to overhead tank,unloading from tanker, washing and cleaning of parts, food and dairy products, beverages, etc. Further, these SS Centrifugal Pumps are widley used in sugar, paper, chemical, petrochemicals, refinery, and other industries.

Key Features:

Superior performance
Rugged construction
High efficiency
Enhanced durability

SS Centrifugal Pumps

Complete SS 316 Horizontal Centrifugal Pumps are available with high head as well as high discharge design. Hydraulically balanced impeller is available to provide economical performance by consuming less energy. They are available with the efficient sealing arrangement by Carbon v/s Ceramic Mechanical Seal that well-suited almost all kinds of liquids. Special seal or gland packing is also done on request. They are ideal for chemical transferring from underground to washing and cleaning of parts, overhead tank, unloading from tanker, food and dairy products, beverages etc.

Specifications:

At 2900 RPM				Max, Temp. 250o C
Pump Model	HP	Suc X Del Size	Head in Mtrs./Capacity in M³ /hr
Pump Model	HP	Suc X Del Size	6		10	12	16	20	24	28	32	40	45	48
CFP-01	0.25	12 X 12	26		14	10
CFP-02	0.50	25 X 25 40 X 40	120		100	85	50
CFP-02	0.50	25 X 25 40 X 40	200		150	80	30
CFP-03	1	25 X 25 40 X 40				150	130	100	70	40
CFP-03	1	25 X 25 40 X 40			280	260	220	150	100
CFP-04	1.5	40 X 40 50 X 50					240	160	130	95	50
CFP-04	1.5	40 X 40 50 X 50				280	230	170	135	95
CFP-05	2	40 X 40 50 X 50						200	175	135	90
CFP-05	2	40 X 40 50 X 50				350	270	180	150
CFP-06	3	50 X 40 65 X 50					275	230	210	190	160
CFP-06	3	50 X 40 65 X 50				630	540	380	250	175		80
CFP-07	5	50 X 40 65 X 50								300	260
CFP-07	5	50 X 40 65 X 50					710	630	570	300	230	190	145	90
CFP-08	7.5	65 X 50 100 X 75						800	720	670	590	100
CFP-08	7.5	65 X 50 100 X 75				1250	1180	980	820			300
CFP-09	10	65 X 50 100 X 75								825	725
CFP-09	10	65 X 50 100 X 75					1400	1200	1160	1000	700	620	510	410

Versatile Application Across Industries

These SS Centrifugal Pumps cater to a diverse range of sectors, from water transfer and chemical processing to pharmaceuticals, food, dairy, and CIP systems. Their robust design and multiple connection standards ensure compatibility and reliability, whether used in industrial, commercial, or hygienic settings.

Engineering for Performance and Longevity

Designed with mechanical seals, ball bearings, and single volute construction, these pumps provide consistent, high-efficiency operation. They can handle pressures up to 10 bar and temperatures up to 120C, while the mirror or matte surface finish ensures corrosion resistance and sanitary performance, vital for sensitive processes.

FAQs of SS Centrifugal Pumps:

Q: How do SS Centrifugal Pumps ensure leak-free operation in demanding environments?

A: SS Centrifugal Pumps utilize mechanical seals, which are designed to prevent leakage even when handling corrosive chemicals or high-temperature fluids. This ensures safety, minimizes maintenance needs, and extends pump service life in industrial and hygienic processes.

Q: What are the main benefits of choosing a baseplate-mounted centrifugal pump with SS construction?

A: Baseplate mounting offers stability and ease of alignment, while stainless steel construction ensures resistance to corrosion, ease of cleaning, and long-term reliability. This makes the pump suitable for process industries, food processing, and pharmaceuticals.

Q: When is it advisable to use a pump with a single-stage, single-suction, end suction/top discharge configuration?

A: This configuration is ideal for applications requiring efficient liquid transfer at moderate to high flow rates and heads, such as in water supply systems, CIP operations, and chemical processing, where maintenance and accessibility are important.

Q: Where can these pumps be effectively installed, considering their ambient and process temperature range?

A: These pumps can be installed in environments with ambient temperatures up to 50C and handle pumped fluids up to 120C, making them suitable for both indoor and outdoor industrial setups, including processing plants and utility areas.

Q: What process advantages do DIN/BS flange and BSP threaded connections provide?

A: These international connection standards allow for flexible installation, easy integration with existing piping systems, and improved sealing reliability across various industrial applications. This versatility simplifies retrofitting and new setups.

Q: How does the ball bearing design improve pump usage and lifespan?

A: The use of ball bearings reduces mechanical friction, facilitates smooth rotation at speeds of 1450/2900 rpm, and increases the overall durability of the pump, resulting in lower maintenance cost and enhanced operational reliability.
